Standard lump breaker
Crushing, lump crushing, granulating
Available in mild steel, stainless steel 304L and 316L
Throughput from 1 to 50 m³/h.
Lump breaker range
The lump crusher is ideal for making a crushing operation of material having a tendency to form clumps. The rapid rotation of the blades causes the fragmentation of clods.
Our lump breakers are the perfect solution for grinding materials that tend to form lumps. The lump crusher allows to break the lumps that form during the production or transportation process of friable materials in powder or grain. The fast rotation of specially shaped blades through a fixed mesh gives an efficient lump breaking action. The presence of two rotors allows high throughputs if required.
-
Precision2
-
Rate5
Before/after
Operating sequence
Their objective is to ensure supply of fluid product.
Lumps must go through a deflector. The lump breaker includes two pin shafts. This model is recommended in the case of friable lumps, without moisture absorption.
The grinder consists of a square section body with an upper and lower flange, 2 parallel horizontal shafts, a mesh for big sizes, 4 shaft bearings with adjustable shaft seal and an appropriate drive unit with transmission.
Customized lump breaker :
Lump breakers are designed by our engineering office in collaboration with our clients to meet their needs and expectations.
The design office PALAMATIC PROCESS is able to offer very specific solutions for your lump crusher applications according to your constraints and your flow rates. We define with you the customized solution after visiting your site and according to your detailed specifications.
Lump crusher integrated features :
- A blades or knives
- ATEX standards 20/21/22
- Passage of the product dimension
- Engine speed fixed or variable
- Controller of rotation
- Steel or stainless steel construction
- A chain drive or gear
- Contact safety
Equipment advantages
- ATEX standards 20/21/22
- 3 standard sizes
- Built with 2 rotors with blades for lump breaking and a mesh in order to reduce the passage space
- Fixed or variable speed motorization, chain or gear drive
- Manufacturing: mild steel, stainless steel 304L and 316L
Media
View our equipment in videos
Lump breaker Palamatic Process
It is used to break up materials that tend to form lumps and to ensure a fluid supply of the bulk material.
Lump breaker Palamatic Process
The rotation of special knives through a fixed grid causes the breaking of lumps.
Lump breaker with knives
The presence of two rotors allows high flow rates to be achieved.
3-D Lump breaker
3D view of the Palamatic Process industrial lump breaker.
Industrial lump breaker
View our equipment in photos
Gamme des émotteurs
3 Palamatic Process lump breakers for crushing, lumping and granulating.
Lump breaker EC70 Palamatic Process
The lump breaker EC70 shreds and deagglomerates bulk materials that tend to build up in mass.
Examples of tests
Test for crumbling frozen zucchinis.
Lump breakers
The lump breaker crumbles the bulk materials and are suitable for compact materials with large lumps.
Lump breaker Palamatic Process
Lump breakers crush and crumble bulk materials and ensure a smooth flow of your product in your production line.
Lump breaker
The lump breaker breaks up the clods that are created during the production process.
Lump breakers EC70
Technical information of the EC70 lump breaker :
- Rotor speed: 180
- Flow rate in t./h : 50 to 80
- Material cross-section in mm: 700*700
- Motor power in kW: 5.5
- Mounting flange in mm: 800*800
- Weight in kg: 345
Industrial Lump breakers
The Palamatic Process lump breaker is present in our test station. You can thus carry out your tests with your powders and according to the chosen configuration.
Lump breaker Palamatic Process
L'émotteur est disponible en acier peint, inox 304L et 316L.
Lump breaking process
Examples of processed powders: clay, glucose, salt, sugar, milk powder, animal flour, soya, starch...
Lump breaker bulk materials handling
Lump breaker for loading resin into ATEX 20 under pressure reactors.
Micronization
The lump breaker can work in continuous feeding or under load under hopper.
Frozen materials lump breaker
Test example: crumbling of frozen carrots.
Knife lump breaker
The lump breaker shreds and deagglomerates bulk materials that tend to build up in mass.
Knife lump breaker Palamatic Process
Shaft passage sealing.
Lump breaker below bag dump station
The conveying of the powders is carried out by VFlow®. The powders processed are sebacic acid, adipic acid, sodium molybdate and benzotriazole.
Paint coatting lump breaking
The lump breaker ensures a supply of de-agglomerated material. It includes 2 pin shafts.
Crushing unit
Two horizontal rotating shafts are equipped with chopping knives.
Industrial lump crusher
The DLP Lump Breaker is the ideal device for breaking up material lumps.
De-lumping unit
Breaking up friable lumps in bulk materials.
Features
Technical specification
| Models |
rotor speed tr/min |
Theorical flow in m³/h | Product section passage in mm | Engine power in kW | Mounting flange in mm |
Weight (kg) |
|---|---|---|---|---|---|---|
| EC35 | 200 | 25 to 35 | 375*375 | 3 | 445*445 | 220 |
| EC50 | 180 | 40 to 50 | 525*525 | 5.5 | 600*600 | 280 |
| EC70 | 180 | 50 to 80 | 700 *700 | 8 | 800*800 | 345 |
